Affordable Tools to Find and Mark Underwater Explosive Ordnance

Background

Following conflicts across the world, millions of tonnes of explosives remain underwater in inland, ocean, and coastal waters. Whether dumped post-conflict, sunk in combat, unexploded following failed deployment, or from inland battles that spilled into waterways, the hidden danger of underwater explosive ordnance now affects communities across the world.

The problem of explosive ordnance (EO) is pervasive and global. In contexts where the UN is engaged in Mine Action, from the Solomon Islands and Papua New Guinea, through to modern conflict spillover in Yemen and Ukraine, the lack of knowledge about the location of underwater EO hampers the lives and livelihoods of communities who rely on these waters.

Some EO beneath the waves and currents aren’t only explosives. They can also contain toxic materials, including chemical weapons or carcinogenic chemicals, which – as they corrode and break down – leach into the surrounding water. This results in damage to the environment, wildlife, and potentially the health of communities who depend on these water bodies for their livelihoods and food.

The effects of underwater EO’s presence, breakdown, and their continued threat has first and second order effects on the nearby communities and humanitarian organizations operating in these regions:

• Risks posed to lives and livelihoods of fishers, divers, and coastal communities by unexploded ordnance,
• The chemical contamination of the water and its animal and plant life,
• In Yemen, the insurance costs for humanitarian shipping operators run to millions of dollars: reducing the potential efficacy and capability of humanitarian support,
• and the presence of EO can delay infrastructure development for communities or commercial ventures

Though the underwater dumping of EO was outlawed when the Convention on the Prevention of Marine Pollution by Dumping of Wastes and Other Matter was adopted in 1972, modern conflict zones (such as Ukraine and Yemen) and legacy post-conflict regions (Solomon Islands, Vietnam) remain affected by the ongoing presence of dangerous materials underwater.

In addition, particularly underwater, the presence of explosive ordnance might be confirmed but its precise location is often unknown. Due to tides, currents, and the natural courses of waterways changing over time, EO can also move.

Whether on land or underwater, the detection and marking of EO for later clearance or mitigation is begun through Non-Technical Surveys (NTS): the gathering of quantitative and qualitative information on the location, nature, and risk assessment about EO. Then, following months or even years of consultation, Technical Surveys are the next step: utilizing technologies like metal detection, magnetometers, magnetic sensors, or sonar to determine the presence, concentration, and location of any explosives.

On land, metal detectors provide even amateur detectorists with the ability to identify and mark the presence of metal under the earth: with ferrous and non-ferrous metals interrupting the device’s generated electromagnetic field and ‘pinging’ the user. When dealing with mines and potentially contaminated areas, humanitarian and military organizations utilize similar technologies that enable detection (and subsequent notification) and ringfencing or geo-marking of the area. For underwater EO, things aren’t so simple: large-scale detection would require high-cost approaches or significant personnel to aid inspections.

The history of innovation in the space – to cut down on the often-lengthy process of Technical Surveys - is well-known. Rats, dogs, bees, and even dolphins have been trained and used to identify explosives without detonation, and plants and algae that can signal the presence of explosives/the chemicals that leach from their corrosion have also been tested.

To date, however, the major ability to detect and mark the presence of underwater EO sits with the military and commercial operators. The costs of the technology used for detection, the skills to implement them, and then the dangers/risk of removal/remediation of EO means this is often out of reach for the communities who depend on these waters for their livelihoods.

For example, in Ukraine, UNDP and partners have recently trained 15 specialists in the use of remotely operated vehicles (ROV) for location and identification of ordnance at depths of up to 300 meters in the country’s rivers, lakes, and waterways. The game-changing capabilities of the ROVs used in this programme, however, are not able to be scaled across the globe, to mine action programmes operating under budget constraints or different contexts (each ROV costs ~$250,000). In the Solomon Islands, where UNDP works to clear WWII ordnance, the shallow coastline and reliance on funding support means high-CAPEX – if effective – solutions like the ROV would be a wrong-fit at this stage.

Making the remarkable issue of safety from underwater explosive ordnance ‘mundane’, through passing this ability from expensive military or humanitarian-led projects into the hands of everyday people, would result in an extraordinary capability to make coastal and water-reliant communities safer.

UNDP is therefore launching this Challenge to uncover solutions and democratize and make the detection and marking of underwater explosives more affordable and practical.

The Challenge

This Challenge’s core ask is technical: what solution could be the equivalent of a ‘fish finder’ for the detection of underwater explosive ordnance (EO) and the ability to mark their surface location?

UNDP asks Solvers to submit solutions that would enable non-specialists and local community members to:

• Detect the presence of underwater explosive ordnance (EO)
  • The focus of this Challenge is on overcoming the challenge of detecting underwater EO in saltwater. Solutions that work in saltwater, with its salinity and thermocline features, would likely be relevant for inland bodies.
  • The method of detection should not risk activating the EO.
• From 5 meters up to a depth of ideally 30 meters
• Accurately marking or geofencing the surface locations of explosive ordnance
  • Solutions do not need to map the underwater landscape, but they must indicate the surface location of underwater EO.
  • With this location data being shareable and accessible to local communities via low-cost means (e.g., through commercial GPS or mobile apps).
  • Help communities and NGOs develop maps of contamination/risk areas, either in real-time or cumulatively
• With a cost of up to $5,000 USD per device (CAPEX)
• Able to be operated by 1-2 people for at minimum 6 hours a day.
• The device should be able to be carried in, affixed to, or towed by a small boat (for applicability, consider boats in the 20-foot-long range).
• The solution should not be reliant on fuel or consumables. If using electricity, Solvers should detail the ability to recharge using renewables (e.g. batteries should be rechargeable using a solar panel charger, however, direct descriptions of the charger do not need to be included in the concept).
• and enabling future follow-up or remediation plans by national authorities or NGOs

Solvers may be innovative in their proposed method. Tools might include sensors, mapping software, magnetic detection, chemical identification from corroded ordnance, or novel approaches that leverage acoustic, thermal, or other signatures. Modular devices, add-ons to existing equipment, or other approaches are welcome, given they meet the above-listed core criteria. If using magnetic search, your solution must list the associated risks of potential detonation of ordnance and how you would mitigate this.

No matter your method, solutions must prioritize the affordability, practicality, safety, and usability in low-resource, remote, or fragile settings:

• Affordability: Solutions should cost below $5,000 USD (CAPEX), with any OPEX implications of operation clearly marked.
• Practicality: UNDP’s focus is on practical methods that can accurately detect and mark the surface location of underwater explosive ordnance.

  While dolphins have been used to echolocate sea mines, and rats are widely used on land for their ability to smell chemical compounds in explosives, UNDP is most interested in more effective, practical methods. Solvers are encouraged to think outside-the-box, but with a focus on the realistic deployment of a solution to communities around the world.
• Safety: Any solution should not in any way endanger their intended civilian operators. Visual detection and the physical inspection of explosive ordnance, while occasionally used by professional divers licensed and trained in mine action, are not a focus topic for this Challenge.
• Usability in low-resource, remote, or fragile settings: Any successful solution or method for the identification and marking of explosive ordnance underwater must be applicable across the world, in both conflict and post-conflict zones. That means it should not rely exclusively on high-cost or highly specialized training methods, or on methods that require developed infrastructure or power sources unavailable in rural, remote areas.

  In your submission, please consider the widespread applicability of your solution.

Solutions that can indicate the level of risk – such as identifying highly corroded, mobile, or densely clustered build-ups of EO – are also desirable.

Submissions may be early-stage concepts (TRL1-3) or novel combinations of higher TRL components, or proof-of-concept solutions with indicative results and case studies. No matter your approach, any successful solution must be evidence-based and technically grounded, to ensure they can be achieved in real-world contexts.

The goal of this Challenge is to uncover early-stage, technically sound, innovative, and realistic solutions to detect the presence of underwater explosive ordnance (EO) and mark their location.

Your proposal should describe:

• How the solution detects EO to the desired depth of 30 meters
• How it is set up and operated by a non-expert, or with reasonable levels of training
• How it is maintained
• How the system communicates or records the surface location of underwater EO
• How these locations are then exported to low-cost GPS, mobile phones, or other Geographic Information System (GIS)
• Estimated cost to acquire/produce/assemble the solution (CAPEX) for under $5,000 (USD), as well as its running costs (OPEX)
• Any risks involved in the solution’s use or data collection

UNDP is primarily interested in solutions that meet the following requirements:

Must have:

1. Ability to detect explosive ordnance (EO) underwater from at least 5 meters up to a depth of ideally 30 meters in saltwater and freshwater
   • Minimum smallest EO to be detected would be an 81mm mortar bomb (containing approximate 3kg of ferrous metal)
2. Ability to mark the surface location of EO.
   • This data must be able to be transferred/exported to cheap GPS devices, mobile phones, or alternative low-cost geo-marking systems or GIS.
3. Solution for detection and marking of EO must be easily operated and maintained by non-experts.
4. Able to be carried on, mounted to, or towed by a small boat (up to 20 feet long).
5. Rechargeable device using renewables or not require use of fuel/consumables.
   • While the charger does not need to be included in your submission, details of the solution’s OPEX and charging setup are appreciated.
6. Cost constraints: your entire solution must cost ≤ $5,000 USD in capital expenditure (CAPEX) per device, and be able to be operated by 1-2 people for a minimum of 6 hours a day.
   • When detailing the costs involved in purchasing, assembling, or constructing your solution, please be conscious and communicative of all costs involved, including: running costs (OPEX), transportation, maintenance, spare parts, etc.
   • Any reliance on expensive infrastructure, monitoring, or energy sources will not be accepted in this Challenge.
7. Safe to operate, including: no imminent or long-term danger to operators or marine plant/animal life, and no risk of activating unexploded ordnance (UXO) through its usage.
8. Functional no matter the context: your solution’s ability to be used worldwide is appreciated by UNDP. This includes: language-neutral, overcoming potential digital divides in instruction and training, and functionality in different environments/conditions. For instance, if your solution relies on a specific context or territorial feature, it likely isn’t suitable everywhere.

Nice to have:

1. Ability to indicate risk level: mine movement, level of corrosion, concentration of explosive ordnance.
2. Minimal need for technical training or bespoke maintenance.
3. Integration with publicly-available datasets or sharing platforms, to support humanitarian or governmental mapping efforts.

Things to Avoid:
Any use of strong electromagnetic signals could risk detonation of unexploded ordnance.

Overly complex systems, or those which require professional levels of diving, are not of interest in this Challenge.

Solutions with Technology Readiness Levels (TRLs) 1-6 are invited.

The emphasis of this Challenge is on solving the problem worldwide, and Solvers are invited to submit: early-stage designs and concepts rooted in technical evidence, existing solutions or methods that would allow for the above solution requirements, novel arrangements of high-readiness components to achieve the goal, and/or mature commercial or start-up proposals for addressing the problem with UNDP.

This Prize Challenge has the following features:

1. Your IP Rights are protected; UNDP must pay you an award to obtain them.
2. The best solution has the opportunity to win the Award of $20,000 USD for meeting all must-have solution requirements, as solely determined by UNDP.
3. Awards will be contingent upon the theoretical evaluation of your proposal by UNDP against the Solution Requirements.
4. To receive an Award, Solvers are required to grant non-exclusive license rights to the Intellectual Property (IP) in their proposed solution. Solvers will retain all rights to any proposal not awarded.
5. Awarded Solvers will also grant a license to UNDP to make awarded solutions freely available to other non-profit organizations to help improve mine action capabilities globally.
6. UNDP is willing to consider a collaboration agreement if non-exclusive IP rights cannot be transferred by a Solver that is an organization owning the IP rights in their proposed solution.
7. UNDP may also issue “Honorable Mention” recognitions for notable submissions that are not selected for monetary awards.
